Adjustable Mill Cut, C Type safety chucks are used to change the position of the web as the machine is operating. The pocket is heat treated for durability.
Set includes two safety chucks. One piece has a drive shaft for mounting a brake or clutch and the other piece has a hand wheel for adjustment.
| Capacities | |
| Max Roll Weight Per Set | 3,100# [1,406kg] |
| Maximum Torque Shafted Side | 220.0 ft·lbs (2,640.0 in·lbs) [30.4kg-m] [298N-m] |
| Features | |
Entry Angle |
90° |
| Replaceable Insert | No |
| Sliding Adjustment | Yes |
| Installation | |
| Mounting | Foot |
| Winding Shaft Length Requirement |  |
| Alignment |  |
| Support | |
| Phone and email Support | |
| Warranty | |
| Replacement Parts | |
| Compare To | |
| JRC Web | PIO/W35 |
| Niika | PIO/W35 |
| Boschert | 30-40 |
| Condition | |
| Product Condition | |
Safety Chucks
- Brand: JRC Web Accessories Categories: - Set
- Part #: 503360
- Availability: Ships in 10 - 12 weeks from our factory in Fairfield, NJ USA
-
$4,440.00 Set
-
-
Quantity Discount
1
2-41.5%
5-92.5%
10-147.5%
15-2410%
25-4915%
50+17.5%
